plastic bag product machines

Payment Terms: T/T,L/C
Place of Origin: Zhejiang, China (Mainland)
inquire
Add to My Favorites
HiSupplier Escrow
Share |

Product Detail

Model No.: GFQ500/1200
Production Capacity: 1000sets/year
Delivery Date: 25 working days
Brand Name: Changyin
Function: to produce vest and flat ba...
Certificate: CE,ISO9001:2000
Means of Transport: Ocean
Packing: wooden case package
Plastic Type: PP/PE
Specification: CE,ISO9001:2000
Patent Rights: CE,ISO9001:2000
Export Area: global

It is used for producing best bags and flat-opening bags with pringting.The main motor adopts frequency control of motor speed to save more electricit

Performance and Characteristics:

It is used for producing best bags and flat-opening bags with pringting.The main motor adopts frequency control of motor speed to save more electricity and regulate speed more freely.The color code tracker with good performance makes the sealing and cutting length more accuralte and the error smaller .it adopts advanced computer to adjust length more freely and accurately.

Main technical variables:

Model: GFQ-500

Max. width of bag making: 450mm
Max.length of bag making: 950mm
Speed: 30-130pcs/min
Power of motor:0.75kw
Outline dimension: 2900X1200X1550mm
Weight: 650kg

Model: GFQ-600
Max. width of bag making: 550mm
Max.length of bag making: 950mm
Speed: 30-130pcs/min
Power of motor:0.75kw
Outline dimension: 2900X1350X1650mm
Weight: 750kg

Model: GFQ-700
Max. width of bag making: 650mm
Max.length of bag making: 950mm
Speed: 30-130pcs/min
Power of motor: 1.5kw
Outline dimension: 2650X1400X1350mm
Weight: 800kg

Model: GFQ-800
Max. width of bag making: 750mm
Max.length of bag making: 950mm
Speed: 30-100pcs/min
Power of motor:1.5kw
Outline dimension: 2900X1450X1550mm
Weight: 850kg

Model: GFQ-1000
Max. width of bag making: 950mm
Max.length of bag making: 1200mm
Speed: 30-100pcs/min
Power of motor:2.2kw
Outline dimension: 3200X1550X1750mm
Weight: 900kg

Model: GFQ-1200
Max. width of bag making: 1150mm
Max.length of bag making: 2000mm
Speed: 30-80pcs/min
Power of motor: 3kw
Outline dimension: 3400X1750X1850mm
Weight: 1000kg
